Product Features:
CE certified, RoHS compliant.
Frequency adjustment: the output frequency of the controller can be adjusted to facilitate the user to find the best operating frequency of the vibrator to get a more stable, quiet, energy-saving feeding effect.
High-precision automatic voltage regulator: built-in digital voltage regulator circuit, can automatically eliminate the power supply voltage fluctuations caused by changes in feed speed.
Adjustable start: At startup, the output voltage will gradually increase from zero to the default voltage to eliminate the impact on the vibration plate. The slow start time can be digitally preset.
Switch sensor full / material empty shutdown: support NPN-type sensor or PLC remote material full / material empty shutdown control.
Photoelectric sensor material full / material empty shutdown: support for photoelectric on the radio sensor full / material empty shutdown control.
Remote speed control: you can directly use the external potentiometer, PLC or 1 ~ 5V voltage signal remote control output voltage.
DC control output: the controller can output DC low voltage control signal to drive the solenoid valve and other equipment and the controller work together.
Keyboard lock: long press the / key to lock all the keys to prevent the user misuse.
Maximum output voltage setting: Set the maximum adjustable voltage to prevent the user to misuse the output of excessive voltage damage to vibration equipment.
Digital overtemperature protection: When the controller operating temperature is too high will stop the output to self-protection.
Overcurrent protection: When the controller operating current exceeds the rated current will stop the output to protect the controller and vibration equipment.
Recoverable short circuit protection: When the output is shorted, the controller will stop output and the fuse will not be blown to protect the controller and vibration equipment. The output terminal is no longer short-circuit, the controller can be re-normal work.
Size and weight:
Size: Length 190mm × width 147.8mm × height 94.5mm
Weight: 1675g (without accessories)
